DIGIDALE Precision-Telescopic Belt Conveyors meeting the increased demands of today's warehouse and distribution centres. Digidale Telescopic belt conveyor satisfy all criteria provide cost effective and speedy vehicles loading and unloading trucks, trailers, containers and vans etc., Warehouse storage, packaging area, bags or cardboard storage etc., Digidale will provide selection, design and manufacturing of Telescopic Belt Conveyor as per the customer requirement.
Digidale precision - Telescopic Belt Conveyors meeting the increased demands of today's warehouse and distribution centers. Digidale Telescopic belt conveyor satisfy all criteria provide cost effective and speedy vehicles loading and unloading trucks, trailers, containers
and vans etc., Warehouse storage, packaging area, bags or cardboard storage etc., digidale will provide selection, design and manufacturing of Telescopic Belt Conveyor as per the customer requirement.
The Digidale Engineering Pvt. Ltd. introduces telescopic belt conveyor that will reach right to the end of the vehicle. The machine does not have to move during the loading or unloading process making it ideal for use with a conveyor system.
The telescopic boom and belt drive are controlled via simple to operate push button controls fixed at the end of the telescopic boom. The boom can be extended or retracted to where the operator requires with the remote push button station also.
Function :- Loading & Unloading of truck, containers, trailers, warehouse storage, packaging areas, bags / cardboard storage etc.
Benefits :- Cost reduction, Faster handling time, Ease of operation.
Applicable Industries :- Cement, fertilizer, chemical, food, pharma, paper, floor mills, etc.,
The advantage of using cantievered Telescopic belt conveyor over conventional conveyors on castors is that it will function without contact with the floor rendering them simple and easy to use with minimum of effort.
Digidale will provide selection, design and manufacturing of telescopic conveyors as per the Digidale manufactures a specialized Telescopic Belt Conveyors for loading and unloading applications. We design and build each conveyor to fit your needs.
MODEL |
CLOSED |
EXTENSION |
OVERALL LENGTH |
BELT WIDTH |
DIGI - T |
6 mtr. |
4.5 mtr. |
10.5 mtr. |
1000 mm ( max ) |
STEP 1 : Determine the necessary clearance for building wall, dock levelers. ( A )
STEP 2 : Determine required trailer penetration ( B ).
STEP 3 : A + B = Cantievered Extension ( Telescopic Length )
STEP 4 : Refer to digidale model table above. |
